SMT9808M
Core Features of 10.1inch Car Monitor/Screen
Adopting the high-performance processor and Linux operating system, it is a core product of new-generation wireless vehicle video surveillance solutions that uses H.264 video compression/decompression, GPS positioning and wireless data transmission technologies. The device is specially designed for mobile video surveillance for different types of vehicles, such as buses, long-distance coaches, taxis, logistics vehicles, armored cars, private cars, etc.
Hisilicon HI3520D solution, H. 264 compression mode, multi-stream recording, up to 1080P high-definition video recording effect.
8V-36V adaptive wide voltage input range (over 42V Automatic Shutdown Protection) , Low-power electronics, suitable for all kinds of cars, big cars and special vehicles.
Professional design of vehicle power supply protection, good heat dissipation performance, with international standards of power polarity reverse protection, loss/overvoltage/overcurrent protection, short-circuit protection.
UPS Power Technology, in the case of sudden abnormal power outage, can be normal to save video, video recording process will not miss the loss of video.
Automatic trigger display function (IN1-IN6 can be set to trigger the input function, the screen automatically switch to display the corresponding screen) .
HD resolution 1920x1080(including video input, output and video resolution) .
Support HD 1080P, 960P, 720P, TVI CVBS and other video formats mixed input.
Support multi-disk cycle storage, main stream storage, small stream storage and other storage strategies.
Support 4T hard disk and 1TB SD card video, using aviation shock-proof material to reduce the vehicle vibration caused by data damage, the product can adapt to more harsh road conditions.
A variety of display modes, can be set as an independent boot screen, to meet the special needs of different users.
Advanced raw disk + pre-partition storage technology, solve the problem of easy damage caused by uneven disk writing, solve the problem of file fragmentation caused by repeated erase, solve the problem of data loss caused by memory file system crash, can not find the memory and file garbled characters, solve the problem of data loss caused by time confusion, ensure the data integrity and effective, The data is stored in a special way to solve the problem of data confidentiality.
The exclusive naked disk storage technology perfectly solves the problems of missing seconds, losing seconds and not being able to effectively store video data of other products on the market.
Each way of camera screen, can be set up independently left and right mirror, up and down flip, rotate 90 degrees, rotate 270 degrees function.
Each camera screen can be set independently brightness, contrast, saturation, chroma and sharpness.
Each road camera screen, can be set independent of the traffic ruler line (users can adjust the location and width of the auxiliary line) .
Each way of camera screen, can be independently set mobile magnification, cut around the video does not need the screen.
Support the video output of the up-down-left-right margin screen zoom adjustment, adapt to a variety of screen full display, not cut.
DC12V power supply output, for cameras and monitors and other peripheral equipment constant voltage power supply.
Real-time HD video recording, video 1080P/720P/d 1 optional, frame rate adjustable quality.
Road alarm input (door, lights, steering, braking, reversing more than various types can be configured) , can be linked to a variety of responses.
2-way alarm output, support linkage sound and light alarm, power cut off oil.
Remote support audio and video monitoring, two-way voice intercom, manual alarm, over-speed alarm, and line deviation alarm.
Display and record vehicle running status, license plate, line, over/low speed and other vehicle information for easy management.
Powerful client program, providing real-time monitoring, listening to intercom, playback, video, high-definition screenshots and other functions.
Support to turn on/off OSD character overlay (time, date, channel number, vehicle information, etc.) .
Support 3G/4G/WIFI//GPS/BD/module expansion. 3G/4G/WIFI can be used to realize remote monitoring (real-time video, monitoring, intercom, broadcast. video query, playback, download. parameter settings, firmware upgrade) .
Support Simplified/Traditional Chinese, English, Korean, Russian and other multi-language menu (can customize other language menu) .
Support Boot LOGO customization.
Support configuration parameters export, import function.
TF card, U disk can be used for software upgrade or remote upgrade.
Support mobile phone and PC remote monitoring, video recording support in the machine playback.
Can be customized according to customer functional needs.
Scenes Solutions
Application: Buses, School Bus,Freigt Truck,RV,Ship & Crane,Forklifts,Emergency & Rescue,Tax,Rail Transit,Agricultual Vehicles,etc.
Freigt Truck
School Bus
RV
Taxi
Rail Transit
Forklift
Bus
Emergency & Rescue
